RAL 7026 Granite Grey Paint

Color Image

Actual color may vary from on-screen representation. Please view a physical color swatch or material sample to confirm your color choice prior to purchase.

  • Image Code
  • HTML
  • URL
  • Direct Image Link
Copy below code in your post
Fast Shipping

70% of Orders Ship within 3 Business Days.

Ready to purchase? Select your options in the 4 steps below.

Step 1: Select Paint Type / Application

Spray, OEM, Bottles and Pens

House and Wall Paint

Epoxy, Urethane, and Colorant Concentrate

RAL7026 Granite Grey is a very dark, understated near-neutral grey from the RAL Classic collection, providing a muted, technical, and low-visibility appearance ideal for industrial and architectural finishes. With an L value of 26.22 and LRV of 4.82, it absorbs most visible light and appears among the darkest of industrial greys. The subtle cool undertone, with a of -4.41 and b of -3.11, places it slightly toward blue-green yet close to true grey, aided by a hue angle of 215.19 degrees and a moderate chroma of 5.4 for visual depth. Finish affects appearance: high-gloss surfaces may seem lighter, while matte increases perceived darkness and obscurity. Common applications include factory equipment, machine exteriors, metal building panels, architectural steelwork, and vehicle parts where unobtrusive, low-glare, low-visibility color is necessary. Its low lightness and cool neutrality mask dirt and wear, making it highly practical for sites demanding subtle, utilitarian finishes.

RAL7026 Granite Grey is chosen for situations where a very dark, nearly black but still visibly grey finish is required. Best suited to contexts where a consistent, subdued color is essential without being as indistinguishable as pure black. The gloss level influences apparent color depth and ability to mask imperfections, and its cool undertone can appear bluer under daylight or beside warmer materials.

Digital approximations
Values
HEX: #344043
RGB: 52, 64, 67
LAB: 26.2, -4.4, -3.1
Insights
- LRV 4.82 and L 26.2 indicate a color that will read very dark on most substrates, especially in low lighting.
- a (-4.4) and b (-3.1) values confirm a cool, near-neutral grey with no perceptible warm or vivid hue.
- Moderate chroma (5.4) ensures it is not flat black but maintains visual interest and depth.
Digital values are approximations. Paint appearance varies by finish and lighting.

Similar colors:
RAL 7016 Anthracite Grey Paint Anthracite Grey: slightly lighter and less blue, often reads as a deep charcoal.
RAL 7021 Black Grey Paint Black Grey: marginally darker with less chroma; appears almost black in low light.
Tiger Drylac™ 049/82830 RAL 9005 Jet Black: fully black, no visible chromatic undertone, deeper and more neutral than RAL7026.

Product Data

About RAL

RAL is a European Color Standard often used for powder coating products and equipment. MyPerfectColor helps manufacturers; fabricators; refurbishers; equipment supply, rental and maintenance organizations save money and improve quality through exact match color solutions. Some common requests we receive for RAL Colors include spray paint, pens and bottles used for touch up and OEM applications.

Representation of the RAL Colours is done with the approval of RAL gGmbH, 53111 Bonn, Germany.

Please note that the representation of colours on the website can only approximate the actual RAL colour shades as they are registered as varnish samples.

RAL CLASSIC © RAL, Bonn 2019.

RAL DESIGN SYSTEM © RAL, Bonn 2019.

RAL EFFECT © RAL, Bonn 2019.

RAL colors may vary from RAL Color Standards based on lighting conditions, angle of view and/or due to differences in pigments, manufacturing process, substrate and/or limitations in the color capability of the paint.

Frequently Asked Questions About RAL 7026 Granite Grey Paint

When should I send a sample for RAL 7026 Granite Grey instead of ordering a standard RAL7026 match?

Send a sample when acceptance depends on matching an existing coated part, not just the RAL standard. A RAL code defines a target color, not the coating process, texture, or sheen.

  • Standard RAL7026 is appropriate when: crossmaterial coordination is needed and textures/sheens already differ; repairs are lowcriticality (small chips); or acceptance is against the RAL reference, not an installed part.
  • Provide a sample (or specify the OEM powder code) when: surfaces are highvisibility; areas are large or multipanel; inspection is strict or against an existing part; a specific powder texture or lowgloss is present; or a known OEM formula exists.
  • What to send: a flat representative piece (~25×50 mm or larger), mark the face to match, note sheen/texture and process (powder/liquid), and include any supplier/batch info. A samplebased match aligns both color and sheen to your acceptance target and reduces rework risk.
How does sheen affect acceptance when touching up RAL 7026 Granite Grey?

Sheen is a common reason touchups are rejected. RAL 7026 specifies the color only. Dark colors like RAL 7026 make gloss differences read as color shift.

  • Define the required sheen (e.g., highgloss, semigloss, satin, matte). If possible, measure the existing part's 60 degrees gloss and specify a range.
  • Powder textures and matte finishes scatter light; a smooth liquid touchup at a different gloss will stand out. For textured or very lowgloss parts, use a samplebased match and plan blending accordingly.
  • If acceptance compares to an existing assembly, match that assembly's sheen/texture. If acceptance is to the RAL standard and only functional protection is needed, a standard RAL7026 in a practical sheen may be sufficient.
Do I need a primer before applying RAL 7026 Granite Grey on my substrate?
  • Bare carbon steel: Use a corrosionresistant primer (e.g., zincrich or epoxy) after cleaning and removing mill scale/rust.
  • Galvanized steel: Degrease, remove passivation/oxides, lightly abrade, then use a galvanizedcompatible primer (wash/epoxy).
  • Aluminum/stainless: Degrease, scuff, then use an etch or epoxy primer for adhesion.
  • Plastics: Clean, identify resin. Most require an adhesion promoter; PP/PE often need specialty surface treatment before primer.
  • Previously painted: Clean, degloss/scuff, spotprime any exposed metal or repairs. If the old coating is unknown, do a small adhesion test before full work.

In corrosive service or when adhesion is uncertain, use a primer appropriate to the substrate and environment. If an OEM system is specified, follow that system over the RAL 7026 color callout.

What surface prep is required to repair RAL 7026 Granite Grey on existing parts?
  • Confirm acceptance target: match the RAL standard, or match the existing part (color + sheen/texture).
  • Clean thoroughly: remove oils, dirt, and salts with appropriate cleaner; rinse and dry.
  • Remove corrosion and loose coating: wire brush or sand to sound substrate; feather edges of existing paint.
  • Scuff/degloss surrounding area to promote blend and adhesion (typ. 320-600 grit for primers, finer for topcoat touchups).
  • Prime as needed based on substrate and exposure; allow proper flash/cure.
  • Mask to control overspray. Apply light, multiple coats of RAL 7026, allowing flash between coats; blend slightly past the repair area.
  • For textured or very matte powder coats, expect some visibility with spot repairs; consider a samplebased match and, if critical, a panel or edgetobreak repaint.
  • Verify color and sheen under the intended lighting before release to service.
When will I receive my paint matching RAL7026 Granite Grey? Can I get it right away?
All paint is custom-made to order. Most orders ship quickly—often within 1–2 business days—though actual lead time can vary based on production volume. Custom spray paint, paint pens, and brush-in-cap bottles, including colors matched to RAL7026 Granite Grey, typically ship within 1–2 business days. During peak periods, lead times may vary slightly. Transit time depends on your location and the shipping method you choose. If timing is critical, select Expedited Production at checkout—most expedited orders ship within 24 business hours—or contact MyPerfectColor so we can help confirm timing for your specific deadline. Learn more about paint production lead times.
Can I use RAL7026 Granite Grey for touching up powder coating?

Yes, our spray paint, paint pens and touch up bottles are ideal for touching up parts of all kinds, including powder coatings. However, keep in mind that our version of RAL7026 Granite Grey is based on the color swatch contained in the official RAL color book. The color and sheen of your specific production parts may be different. If you need a touch up application, we can create a touch up solution precisely matching your specific parts.

Learn more about our color matching service.

What are the RGB, HEX and LRV values for RAL7026 Granite Grey?
The RGB values for RAL7026 Granite Grey are 52, 64, 67 and the HEX code is #344043. The LRV for RAL7026 Granite Grey is 4.82. The LRV stands for Light Reflectance Value and measures the percentage of light that a color reflects. Learn more about using RGB and Hex codes for matching colors.
What is spray paint matched to RAL7026 Granite Grey made of? And how much area will one can cover?

MyPerfectColor spray paint is a fast-drying durable acrylic enamel coating suitable for interior or exterior use. MyPerfectColor custom spray paint matched to RAL7026 Granite Grey enables you to conveniently achieve a professional spray-smooth finish in any color in any sheen. It sticks well to most surfaces including metal, plastics, powder-coatings, cabinets and primed or previously painted wood.

The MyPerfectColor 11oz spray can will cover about 20 square feet per coat. Keep in mind that it is difficult to gauge spray paint need as the coverage is highly dependent on how it is applied. Learn more about how spray paint works at MyPerfectColor.

How to buy paint for RAL7026 Granite Grey?
Many types of paint are available for RAL7026 Granite Grey with no minimum order quantities. MyPerfectColor offers spray paint, paint pens, touch up bottles, water-based acrylics, epoxies, urethanes and a variety of other paints. Select the Paint Type button above to get started. Learn more about buying paint at MyPerfectColor.
How do I get the SDS (Safety Data Sheet) for paint matched to RAL RAL7026 Granite Grey?
The RAL7026 Granite Grey is the color and the SDS is based on the type of paint used to make the color. You can find Safety Data Sheets here for our most popular products.
Do I need a primer for RAL7026 Granite Grey?
The need for primer for RAL7026 Granite Grey depends on the type of paint, the substrate being painted and where it will be located. See our Primer Selection Table to see what primer you might need and learn more about when you might need a primer. Most people don't use a primer for a touch up paint application, but a primer may improve adhesion and is typically recommended for exterior applications.
How do I convert RAL7026 Granite Grey to a different color from another paint company?

While we can provide RAL7026 Granite Grey in paint, we don't provide any crossover information. We've found that every paint company offers its own unique selection of colors and rarely does a color have an exact equivalent in another brand.

However, under the color image on a color page there is a link that says "Explore Colors". Clicking this link displays colors with similar values and you can look for any colors from the brand you want.

Keep in mind that this just shows similar colors based on the color values we have stored in our database. It doesn't mean it is the same or give any approximation about how close the color is. You can play around with the Hue, Lightness and Chroma sliders to expand the selection.
